This is a CPE WiFi router with a SIM card slot and 5G LTE connectivity. It supports 2.5GHz WiFi with up to 150~300Mbps data transfer rate.
The router is compatible with SIM card bands at N1/N3/N28+N41/N78 (more frequency can be added)
Specification
1.【Dual-Band Wi-Fi6 Router】Elevate your connectivity with the next-gen Wi-Fi6, delivering lightning-fast speeds for downloads, streaming, and transfers like never before. Experience super-fast dual-band Wi-Fi, reaching speeds of up to 600Mbps on the 5 GHz band and 433Mbps on the 2.4 GHz band. This exceptional wireless performance allows for simultaneous online gaming and HD video streaming, while effortlessly sharing large files across multiple devices.
2.【Easy to Use】Simply insert the Nano SIM card in the router, connect the power, and start enjoying stable and fast wireless networks.Just easily connect to WiFi whether it's your cell phone, laptop, desktop or tablet.
3.【Converting 5G signals to LAN】There are 1Wan and 2 RJ45 Ethernet LAN port available which enable desktop computer access to internet via a network cable.
4.【High Gain Antenna】8 internal high gain antennas greatly enhance the sensitivity of the router; it can improve the signal quality of 5G and WiFi, which is convenient for establishing WiFi connection in apartments, trucks, remote mountain villages, or when temporary use of the Internet is needed.
5.【Multi-Device Sharing】The sim card dongle supports access to 32 devices. As long as there are WiFi-enabled devices, they can be connected and used, such as mobile phones, smart robots, iPads, sweeping robots, smart speakers, cameras, TVs, computers, etc.
6.【Increase Coverage】Double external atenna. Increase WiFi coverage area and eliminate network dead angle.
Simply Introduction OF Mobile Internet Router 5G:
This is a CPE WiFi routerwith a SIM card slot and 5G LTE connectivity. It supports 2.5GHz WiFi with up to 150~300Mbps data transfer rate.
The router is compatible with SIM card bands at N1/N3/N28+N41/N78 (more frequency can be added)
It supports 32 users at the same time, providing secure internet sharing service for multiple end users, suitable for smartphones, tablets, PCs.
5G CPE router comes with 2 external 5dBi high gain antennas to enhance the signal strength, so you can enjoy reliable wireless connection anytime, anywhere.
Main features of the product:
● High Compatibility: The 5G CPE router is compatible with SIM card frequency bands in the Americas, Europe, Asia, Africa, Southeast Asia and the Middle East.
● High speed: Download speeds up to 150Mbps. Upload speeds up to 50Mbps and wireless transfer rates of 300Mbps.It provides indoor and outdoor WiFi coverage, supports 802.11b/g/n/ac/ax, MIMO technology.
● Easy to Use: The WIFI wireless router has WAN and LAN ports, support wired connection, you can connect to the router through the network cable, you can also insert a SIM card to use 5G Internet access.
● Wide Application: The WIFI wireless router is suitable for installation in home, factory, office, warehouse, garden, parking lot, bringing convenience to indoor and outdoor places without WiFi.
How to Use:
1. Push the SIM slot cover.
2. Insert the SIM card with the card core facing down
3. Plug in the power supply to obtain WiFi
4. Connect to WiFi and surf the Internet.
5. Connect to WiFi, open 192.168.1.1 in the browser to enter the background, here you can change the WiFi name and password or add APN.
| P53 5G CPE Router | ||
| Platform | CPU | UDX710, Dual core A55 1.35G |
| OS | Linux | |
| Memory | RAM | 4Gb, SIP LPDDR4X |
| ROM | 1Gb, external NAND | |
| RF | 3GPP | R8,R9...,R15 |
| Data rate | HSDPA: Max.42.2Mbps（DL）（Category 24） | |
| HSUPA: Max.11Mbps（UL）（Category 7） | ||
| WCDMA: Max.384Kbps（DL）/384Kbps（UL） | ||
| LTE FDD: Max.300Mbps（DL）/50Mbps | ||
| LTE TDD: Max.260Mbps（DL）/30Mbps | ||
| 5G NR TDD: Max.2Gbps（DL）/500Mbps（UL） | ||
| LTE antenna | 1T2R | |
| 5G antenna | 1T4R | |
| WCDMA/HSPA | B1 | |
| TDD-LTE | B34/38/39/40/41 | |
| FDD-LTE | B1/B3/B5/B8 | |
| CA | B1+B3 B1+B1 B3+B3 B39+B41 B39+B39 B40+B40 B41+B41 | |
| 5G NR | FDD:N1/N3/N28(1T2R) TDD:N41/N78(1T4R) | |
| NR ENDC | B3+N41,B39+N41;B1+N78,B3+N78,B5+N78,B8+N78 | |
| output | Class 3 (24 dBm +1/-3 dB) ，WCDMA Class 3 (23 dBm ±2 dB)，LTE Class 3 (23 dBm ±2 dB)，5G NR | |
| WIFI6 2.4GHz | Protocol | 802.11 a/b/g/n/ac |
| Frequency | 2.4GHz | |
| WiFi antenna | 2×2 | |
| Rx Sensitivity | MCS9: -63dBm@10% PER MCS7: -68dBm@10% PER 54M：-70dBm@10% PER 11M：-83dBm@8% PER 6M：-88dBm@10% PER 1M：-90dBm@8% PER | |
| Tx Power | 16dBm(Max) in 11b mode 14dBm(Max) in 11g mode 14dBm(Max) in 11n mode 13dBm(Max) in 11ax mode | |
| Data rates | 11ax:286.8Mbps@TX and 229.4Mbps@RX 11g:54/48/36/24/18/12/9/6 Mbps (Auto Rate Sensing) 11b:11/5.5/2/1 Mbps (Auto Rate Sensing) 11n:150 Mbps /…/6.5Mbps (Auto Rate Sensing) | |
| WIFI6 5GHz | Protocol | IEEE 802.11 a/b/g/n/ac/ax |
| Frequency | default 5GHz | |
| WiFi channel BW | 20/40/80MHz | |
| Rx Sensitivity | MCS9: -63dBm@10% PER MCS7: -68dBm@10% PER 54M：-70dBm@10% PER 11M：-83dBm@8% PER 6M：-88dBm@10% PER 1M：-90dBm@8% PER | |
| Tx Power | 16dBm(Max) in 11b mode 14dBm(Max) in 11g mode 14dBm(Max) in 11n mode 13dBm(Max) in 11ax mode | |
| Data rates | 11ax:Data rates up to 600.4Mbps with 20/40/80MHz bandwidth 11ac:433/390/325…32.5Mbps (Auto Rate Sensing) 11g:54/48/36/24/18/12/9/6 Mbps (Auto Rate Sensing) 11b:11/5.5/2/1 Mbps (Auto Rate Sensing) 11n:150 Mbps /…/6.5Mbps (Auto Rate Sensing) | |
| interface | Key | WPS, RESET, POWER |
| SIM | 1*SIM slot, 1*ESIM | |
| RJ45 | 1 GE port | |
| LED | WIFI, Lan status,4G,5G,Power | |
| USB Port | TYPE-C | |
| DC port | 12V/2A | |
| Software | Language | English ，Simple Chinese, Can be customized |
| Firewall Features | IP Filter， MAC filter ，Speed Limit | |
| Protocol stack | TCP/UDP/HTTP/PING/HTTPS/FTPS/MQTT/MMS | |
| SIM Card | PIN Management | |
| APN Setup | Support | |
| Band Lock | Support | |
| PCI Lock | Support | |
| Cell Lock | Support | |
| Carrier SIM Lock | Support | |
| DHCP Setup | Support | |
| Port Mapping | Support | |
| IP Filter | Support | |
| MAC Filter | Support | |
| Speed Limit | Support | |
| TR069 | Support configure & queries parameters Support remote upgrade Support cycle monitor | |
| WiFi | Support Wi-Fi SSID/KEY setup | |
| Support Encryption: WPA2-PSK, WPA/WPA2-PSK, | ||
| Support SSID broadcasting | ||
| Support Wi-Fi channel self-adapt and select | ||
| up to 10 users or more | ||
| AT command | Support | |
| FOTA | Support | |
| Webgui | Support | |
